Canon expands Cinema EOS System with new EOS-1D C digital SLR supporting 4K video capture



London, UK, 12 April, 2012 – Canon today announces the introduction of the new EOS-1D C, a digital single-lens reflex (SLR) camera targeting the motion picture, television and high-resolution production industries. Delivering outstanding video quality, advanced low light performance and film-like dynamic range, the compact and lightweight EOS-1D C supports in-camera 4K (4,096 x 2,160) video recording with 4:2:2 colour sampling, offering greater creative freedom for video professionals.

The first SLR camera of its kind, the EOS-1D C offers a unique and highly portable package optimised for high-quality video recording. Advanced creative flexibility is provided with support for a range of resolutions and variable frame rates. 4K video is recorded using 8-bit Motion JPEG compression at 24p, and Full HD (1920 x 1080) video capture is available at frame rates up to 1080/60p. The camera supports internal recording to CF cards at all resolutions up to and including 4K, offering enhanced mobility. Video can also be output to external recorders1 via an integrated HDMI terminal using an uncompressed YCbCr 4:2:2 signal.

The EOS-1D C also features Canon Log Gamma, which facilitates the capture of high quality video rich in exposure latitude and dynamic range. Ideal for video professionals who want to retain the maximum amount of information without huge file sizes, Canon Log Gamma offers a dynamic range uniquely comparable to film, minimising shadowdetail loss and highlight-detail loss to provide greater grading freedom for colourists in post-production.

“The EOS-1D C is a fantastic addition to the Cinema EOS System,” said Kieran Magee, Marketing Director, Professional Imaging, Canon Europe. “Since the introduction of Cinema EOS we’ve had an excellent response from professionals who are hugely excited by the image quality and creative freedom the system offers. The new EOS-1D C will expand those creative options further – it’s a unique camera, supporting 4K video recording in a highly compact body that can be used in a number of different ways. We’re very excited to see what the professional community can achieve with it.”

Advanced performance meets creative flexibility

Based on the core specifications of the EOS-1D X, the EOS-1D C provides exceptional image quality and versatility, with an 18.1-megapixel full-frame CMOS sensor. Optimised for high quality video capture, the sensor provides video professionals with the freedom to adjust image resolution to suit a subject or desired output. During 4K shooting pixels are cropped to an area equivalent to an APS-H sensor, preventing the need to resize or scale the image, ensuring maximum image quality. Additionally, a Super 35mm crop in Full HD recording caters for cinematographers who typically work in the Super 35mm field of view.

The sensor provides high quality performance in all conditions, delivering advanced creative blurring and light capturing abilities when used in combination with Canon’s EF Cinema prime lenses. Its size enables professionals to achieve an extremely shallow depth of field with beautiful background blur, and sensitivity up to ISO 25,600 provides excellent quality and reduced noise in low-light situations.

In addition, support for 24, 25, 30, 50 and 60p frame rates in Full HD resolution shooting provides additional flexibility, satisfying the shooting needs of professionals across the industry. Industry-standard timecode and codec support and a choice of compression methods provides compatibility with established workflow processes, facilitating easy editing and grading immediately after shooting.

The EOS-1D C ships with an exclusive software package, including a suite that allows 4K/Motion JPEG and Full HD/60p video shot on the camera to be output on an external monitor2 with no loss of image quality. It also enables video shot with Canon Log Gamma to be output on a monitor with standard video gamma applied.

Additional advanced applications, including Picture Style Editor and EOS Utility, also enable adjustments to various camera settings to be conducted from a PC. Real-time procedures, such as the editing and registration of picture styles or checking results on a monitor, can be conveniently performed on-set using a PC or Mac – allowing users to promptly carry out adjustments, and ensuring efficient shooting and post-production procedures.

EF lenses and EF Cinema Lenses – freedom to explore

As part of the EOS system, the EOS-1D C is compatible with more than 60 EF lenses, all of which offer high resolutions to support 4K image capture. The EF lens series offers exceptional creative freedom, with focal length options ranging from 8mm to 800mm. Over 70 million EF lenses have been manufactured since the EOS system launched in 1987 – a measure of its unparalleled quality and popularity. As part of the Cinema EOS System, Canon has also introduced a range of 4K EF Cinema Lenses, utilising the company’s unique optical heritage to produce leading-quality lenses optimised for high-quality video capture.

Canon EOS-1D C – key features:

  • 4k movies
  • 1080p at 50/60fps; Canon Log Gamma
  • Uncompressed HDMI output
  • 18 MP Full Frame CMOS
  • Up to 12fps stills; 14fps mode
  • 61 point AF system
  • ISO range 100-25600
  • Dual DIGIC 5+ processors
  • Clear View II 8.1cm (3.2″) LCD
  • EF lens compatible

1 Excluding 4K video
2 Requires the use of a PC equipped with an SDI port

Canon EOS-1D C specifications



Body type
Body type Large SLR”
Sensor
Max resolution 5184 x 3456
Other resolutions 4608 x 3072, 3456 x 2304, 2592 x 1728
Image ratio w:h 3:2
Effective pixels 18.1 megapixels
Sensor photo detectors 19.3 megapixels
Sensor size Full frame (36 x 24 mm)
Sensor type CMOS
Processor Dual Digic 5+
ISO 100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, 51200 (50, 102400 and 204800 with boost)
White balance presets 6
Custom white balance Yes (5)
Image stabilization No
Uncompressed format RAW
JPEG quality levels Fine, Normal
Optics & Focus
Autofocus
  • Contrast Detect (sensor)
  • Phase Detect
  • Multi-area
  • Selective single-point
  • Tracking
  • Single
  • Continuous
  • Face Detection
  • Live View
Digital zoom No
Manual focus Yes
Number of focus points 61
Lens mount Canon EF mount
Focal length multiplier
Screen / viewfinder
Articulated LCD Fixed
Screen size 3.2″
Screen dots 1,040,000
Touch screen No
Screen type Clear View II TFT LCD
Live view Yes
Viewfinder type Optical (pentaprism)
Viewfinder coverage 100 %
Viewfinder magnification 0.76×
Photography features
Minimum shutter speed 30 sec
Maximum shutter speed 1/8000 sec
Built-in flash No
External flash Yes (Hot-shoe)
Flash modes E-TTL II Auto Flash, Metered Manual
Continuous drive Yes (14 fps)
Self-timer Yes (2 or 10 sec, remote)
Metering modes
  • Multi
  • Center-weighted
  • Average
  • Spot
Exposure compensation ±5 EV (at 1/3 EV, 1/2 EV steps)
AE Bracketing ±3 (2, 3, 5, 7 frames at 1/3 EV, 1/2 EV steps)
WB Bracketing Yes (3 frames in either blue/amber or magenta/green axis)
Videography features
Format
  • MPEG-4
  • H.264
Microphone Mono
Speaker Mono
Resolutions 4096 x 2160 (24 fps), 1920 x 1080 (60, 50, 30, 25, 24 fps), 1280 x 720 (60, 50 fps), 640 x 480 (60, 50 fps)
Videography notes intra or inter frame
Storage
Storage types Compact Flash (Type I or II), UDMA compatible
Storage included None
Connectivity
HDMI Yes (Mini)
Wireless Optional
Remote control Yes (N3 connector)
Physical
Environmentally sealed Yes (Water and dust resistant)
Battery Battery Pack
Battery description Lithium-Ion LP-E4N rechargeable battery & charger
Dimensions 158 x 164 x 83 mm (6.22 x 6.46 x 3.27″)
Other features
Orientation sensor Yes
Timelapse recording Yes (by cable and PC)
GPS Optional
GPS notes GP-E1, GPE2
